Temperature Data Logger

  • Real-Time Monitor and Record Temperature Changes
  • Reusable
  • No Need for Installation Software
  • Power-Efficient & High Storage Capacity

Product page – 5 tabs

Description

Temperature Data Logger is specially designed for long-term humidity and temperature recording. Temperature Data Logger uses an SD card for a mass storage media which could store 134M points of auto-generated data, providing an accurate record of the humidity and temperature, and the internal analysis software for users to quickly understand all the situations during transportation, storage, and usage of products and equipment.

Temperature Data Logger supports around 4 weeks recording base, which depends on the setting record period, one period could be configured from 1 sec to 12 hrs one record.

The RFID Data Reader, an accessory for Temperature Data Logger, can directly read and display data on the screen of the reader in a short distance, making users tracking the situations of shipment more convenient and time-efficient.

Specification

Product Name
Temperature Data Logger
Dimension
270 x 265 x 29 mm
Accuracy
Relative Humidity: ±2% ( 0% - 100% )
Temperature: ±0.2°C ( -40°C - 125°C )
Max Storage
134,217,724 points(4GB)
Time Stamp
Yes
Record Interval
1, 2, 5, 10, 15, 30 sec
1, 2, 5, 10, 15, 30 min
1, 2, 3, 6, 12hr
Indicator(LED)
Short flash once: recording
Short flash twice: error message
PCI Interface
USB2.0 Mass Storage Device
RFID
ISO 15693, 13.56MHz
Operating Temperature
-20°C to 60°C (-4°F to 140°F)
Power Supply
4.0 to 5.5 VDC
Power Consumption
Sleep 1180uA, Recording 16.4mA*106mS
Water Proof
IP20

Accessary

RFID Data Reader

Reading and displaying the record data of the Temperature Data Logger & Shock Data Logger

RFID Data Reader

Reading and displaying the record data of the Temperature Data Logger & Shock Data Logger



How to use Temperature Data Logger?

  1. Connect Temperature Data Logger to your desktop to set the recording period and synchronize time
  2. Mount Temperature Data Logger on your shipment.
  3. Plug the device into the battery case and the blue LED will flash twice.

How to use the RFID Data Recorder?

  1. Hold the reader about 3 – 5cm from the Temperature Data Logger and press the circular button
  2. The data will be immediately displayed on the screen.
